Acoustic Ring - Ring Direct (2ft to 5ft)

Acoustic Ring Direct RD Series

Fotons Specification grade architectural LED ring fixtures deliver minimalistic and distinctive lines that are able to endorse any design of hospitality, dealership & commercial space.

• Available from 24" to 60" (2ft to 5ft) diameter
• Lumens from 3,400LM to 8,500LM
• Low profile housing 1.3 Width 1.5” height
• Extruded aluminum housing
• 90+ CRI
• Suspended & surface mount

Ring Direct RD Series

1.30''W x 1.50''H

24" to 60" (2ft to 5ft) diameter

 SIZE/LUMENS

• 2440     24” | 3,400LM  2FT
• 3650     36” | 4,250LM  3FT
• 4880     48” | 6,800LM  4FT
• 60100    60” | 8,500LM 5FT
• 78120    78” | 10,200LM  6.5FT
• 118200  118” | 17,000LM 10FT
• 196400  196” | 34,000LM  16FT

COLOUR TEMP.

• 27K  2700K
• 30K  3000K
• 35K  3500K
• 40K  4000K

FINISH

• WH  White
• BK   Black
• Custom Specify Ral# Example: GR Grey (RAL#9006)

MOUNTING OPTION

• SW  Suspended wire
• SC   Suspended canopy
• SM  Surface mount

Spec Sheet:

Acoustic Ring-Direct RD-Spec-Fotons-V1.0-2024

IES File:

Ring Direct-RD2440-40W 24''-ies-Fotons.IES

Ring Direct-RD3650-50W-36''-ies-Fotons.IES

Ring Direct-RD4880-80W 48''-ies-Fotons.IES
